Description
Xantrex 817-1050 is a 1000W continuous-output inverter/charger for supplying compatible AC loads from a 12-volt battery system. Match the connected loads’ running and starting requirements, battery capacity and installation space. Battery cables and a fuse are separate; review the electrical specifications before installation.
Specifications
| Brand | Xantrex |
| Manufacturer Part Number | 817-1050 |
| Output Voltage | 120 Volt AC |
| Input Voltage | 12 Volt DC |
| Continuous Output Power (W) | 1000 Watt |
| Peak Output Power (W) | 2000 Watt |
| Ampere Rating | 8.4 Amp |
| Efficiency | 91 Percent |
| Remote On/Off Capable | Yes |
| With USB Port | No |
| With Volt/Watt Meter | No |
| With Short Circuit | No |
| With Reverse Battery Protection | No |
| With Thermal Protection | No |
| With Battery Cables | No |
| With Built-In Charger | Yes |
| With Fuse | No |
Dimensions
| Length (IN) | 14.2 in |
| Width (IN) | 10.6 in |
| Height (IN) | 3.7 in |
Key Features
- Extended Surge Rating: Surges to 2X Continuous Power for 2 Seconds for Motor Loads.
- True Sine Wave AC Power for Operation of Sensitive and Motor Loads.
- Ignition Control to Turn Inverter on or Off Via a 12 Volt DC Signal and to Minimize Battery Drain by Switching the Inverter Off When the Ignition Key Is Turned Off.
- Wide 10 to 18 Volt DC Input Rang Ensures Inverter Operation on High Voltage Alternators Found on Many New Vehicle Chassis.
- Built-In 30 Ampere AC Transfer Relay Senses When Outside AC Power Is Present and Transfers the Load from the Inverter to the Source of Incoming Power.
- View AC and Battery Current, Percent Status Bar for Inverter Output on the Onboard Display.
- Hardwire or Plug Directly Into the Optional 20 Ampere GFCI Receptacle.
- Easy Access AC and DC Wiring Compartment for Quick Installation.
- Limited 2 Year Warranty.
- It cranks out full output in invert or charge mode from -4 Degree Fahrenheit to 104 Degree Fahrenheit for operation in all climate temperatures.
