Suburban 4-Gallon SW4D Hot Water Heater Direct Spark Ignition 5135A

The Suburban 4-Gallon SW4D Advantage Tank Water Heater with Direct Spark Ignition (DSI) is a high-quality solution designed for efficient and reliable hot water in your RV or mobile home. Featuring a durable porcelain-lined steel tank, it offers long-lasting performance similar to residential tank water heaters. The replaceable anode rod protects the tank from corrosion and serves as a convenient drain.

This model also includes an optional electric element, which allows you to heat water using campsite or generator power. Suburban’s exclusive flue tube design slows the combustion process, enhancing heat transfer to the water, making it more energy-efficient. The repositionable module board offers installation flexibility, while the Direct Spark Ignition (DSI) system eliminates the need for a pilot light, providing easy and reliable operation.

Key Features:

• Durable porcelain-lined steel tank for long-lasting performance
• Replaceable anode rod prevents corrosion and doubles as a drain
• Optional electric element for use with campsite or generator power
• Exclusive flue tube design maximizes heat transfer to the water
• Repositionable module board for flexible installation
• Direct Spark Ignition (DSI) system eliminates the need for a pilot light


Specifications:

• Dimensions: 12.69" x 12.69" x 16.125"
• Cutout Dimensions: 12.75" x 12.75" x 16.125"
• Packaging Type: Single-Pack (A) Only
• BTU/h Input: 9,000
• Optional Electric Element Input: 1,440
• Recovery Rate (Electric Only): 6.1 Gallons/Hour
• Recovery Rate (Gas Only): 7.6 Gallons/Hour
• With Insulation: No
  With Switch: No
  With Access Door: No
  With Indicator Light: No
  With Mounting Hardware: No

• Limited 2 Year Warranty And Limited 3 Year Tank Warranty

Please measure the space of installation to ensure a proper fit *
