Descripción
Equus E6086 puts an 8,000-RPM tachometer in a compact 2.5-inch housing, leaving more room for surrounding gauges than a full-sized pedestal unit. Its black dial has an illuminated pointer, an adjustable redline marker and a broad 270-degree needle sweep.
The electrical gauge is specified for compatible four-, six- or eight-cylinder gasoline engines, with a signal connection to the ignition coil. Pedestal hardware and multi-language instructions come with the unit. It is not a diesel tachometer, and direct coil-on-plug or multiple-spark systems require a suitable signal source to be confirmed before wiring.
Specifications
| Part number | E6086 |
|---|---|
| Product | Mini electrical pedestal tachometer |
| Face | Black |
| Dial diameter | 2.5 in |
| Depth | 2.75 in |
| Scale | 0-8,000 RPM, 100-RPM increments |
| Needle sweep | 270 degrees |
| Adjustments | Shift/redline marker |
| Engine compatibility | Gasoline 4-, 6-, or 8-cylinder with compatible tach signal |
| Included | Pedestal mount, hardware and instructions |
application
| Engines | Gasoline-only; suitable tach signal from conventional/distributorless ignition |
|---|---|
| Not compatible | Diesel engines; incompatible ignition-signal systems |
Before installation or ordering
- Maker guidance requires the green signal wire to connect at the appropriate ignition-coil negative; the inductive pickup clamp is not suitable for this model.
- Before installation, confirm the lamp and wiring requirements in the supplied instructions.
